Product Details:
Payment & Shipping Terms:
|
Power Supply: | AC | Application: | Outdoor |
---|---|---|---|
Lampshade Material: | Toughened Glass | Lighting Bulbs & Tube: | Energy Saving |
Specifications:
Part No. |
ZL-TGD-100W |
|
Optics Parameters
|
Light Source |
1pc bridgelux chip 45mil |
Luminous Flux(lm) |
9800LM |
|
CCT(K) |
warmwhtie(3000K)/white(6000K)/ Neturalwhite4000K |
|
CRI(Ra) |
more than 80Ra |
|
Beam Angle |
120 degree |
|
Light Attenuation ratio (%) |
less than 3% in 30,000Hrs |
|
Lifespan (Hrs) |
more than 50,000Hrs |
|
Electric Parameters |
Input Voltage(V) |
85-265Vac |
Frequency(Hz) |
50/60 Hz |
|
Input Current(mA) |
86mA (@ 220 Vac ) |
|
Total Power(W) |
105W |
|
Power Factor |
0.95 |
|
Turn-on Time(S) |
less than 0.05 S (@ 220Vac) |
|
Dielectric Voltage Withstand Test |
3750Vac/1min |
|
Structure Parameters |
Material |
Aluminum+ PMMA |
Size(mm) |
380*280mm |
|
Net Weight(g) |
7.35KG |
|
Water Proof(IP) |
IP66 |
|
Integrated Parameters |
Operating Temperature |
-40 ~ +55 Centigrade |
Storage Humidity |
0% ~ 95%R.H. |
|
Dimmable |
Optional |
instructions: |
|
1.LED is DC driven, low power consumption device.It is anti-seismic, impact resistant,Non-thermal |
|
radiation,secure stable,reliableWorry free for thermal dissipation, long lifespan, compact |
|
light body ,simple installation chic style, manufacturing excellence and product serration. |
|
2.Energy saving,environment-friendly,waste free,completely recyclable. |
TS have 15W-1000W power for outdoor Flood light
